Dis T.1634007e
The disabled input no longer activates the associated relay output and therefore the
devices connected to it will not be activated. This function can be used to exclude
devices that have not yet been installed or failed or removed for repair.
If the procedure is correct, a window notifies you that the operation has been successful. Then the
screen returns to the beginning of the enable / disable management of the LOGIC INPUT.
LOGIC INPUT – CONFIGURE (Level 2):
In the INPUTS submenu, press
on the screen, press
ENTER
Remember that the Control unit has only one logical input
With
and
you scroll through the different items and then
pressing only the value is selected, showing that you can change it.
Then with
and
you go from field to field on the same line (where applicable) and then
pressing
the change is accepted. Instead, pressing
ENTER
the previous value and the entire row is selected, showing that it is only
possible to scroll through the various items.
The various items are explained in detail below:
Description of items relating to Logic Inputs
Indicates the status of the input. LOW means that it will go into ALARM when the
ACTIVE
circuit is open (e.g. button). HIGH mean it will go into ALARM when closed.
Description of items relating to Outputs (relays):
The description of the items: OUTPUT N, SILENCEABLE, SILENCE, HYSTER.ON, HYSTER.OFF/TIME ON,
POS LOGIC and LATCHED are identical to those of the chapter, CONFIGURE SENSORS
Then at the end of the screen, move to SAVE to save the configuration
entered. By pressing
again to confirm, or
ENTER
After confirming, a window warns that the operation was successful.
Then the screen returns to the INPUTS configuration.
LOGIC INPUT – DELETE (Level 2):
To delete the LOGIC INPUT from the configuration. Press
relevant item and then proceed in the same way as described in the
paragraph
SENSORS-DELETE
Press
to confirm or
ENTER
was not configured, the window warns that the operation is not
possible). After confirming, the window will notify you that the operation
was successful.
Then the screen returns to the beginning of the Delete management.
LOGIC INPUT - MODIFY (Level 2):
To modify a configured LOGIC INPUT, press
same way as described in the paragraph
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
on the item for CONFIGURE. Then
ENTER
to configure the Logic Input.
you change the values, while with
the confirmation window will appear. Press
ENTER
press to go back.
ESC
to return to the previous step. (If the Input
ESC
SENSORS - MODIFY
and
restores
on the
on the relevant item and then proceed in the
ENTER
Pag. 28/52
INPUT CONFIG.
INPUT N.
1
INPUT CONFIG.
INPUT N.
1
ACTIVE
:
LOW
OUTPUT N. :
SILENCE MODE
NO
SILENCE TIME:
NO
DELAY ON :
0s
DELAY OFF :
0s
INPUT
N. 1
CONFIGURED
DELETE
INPUT N.
1
INPUT
N. 1
DELETED
