Dis T.1634007e
Full Charge
Half Charge
If by mistake, the battery (configured present) being disconnected and/or connected with the
control unit, mains powered the yellow LED lights up on fast blinking.
Symbols used to indicate the presence of mains power:
Mains operation (is absent, when the power is by the batteries).
If the control unit, had lost the date and time, due to a malfunction or discharge of the clock
backup battery, screen will be displayed for entering updated values (The unit's safety
functions are guaranteed, except those involving the use of date that will be wrong). By
changing these parameters, see below, the section
The status of a sensor, which appears on the main screen, may be:
Not configured
- - - -
Disable
* * * *
Sensor failure
FAULT
UR not conncted The detector connected to a remote unit that is not connected.
OFF LINE
Normal
NORM.
Alarm 1
AL.1
Alarm 2
AL.2
Alarm 3
AL.3
When a detector, a logic input or a zone, activate a relay output, the summary screen of the status of
the Alarms and Faults appears. This allows checking quickly, the total number of active relays and
their relative alarm level.
The details of the individual items is as follows:
Indicates the number of active relays, relative to the Fault, of a sensor or a group of
FAULT
sensors that belong to a zone.
Indicates the number of active relays, relating to exceeding the threshold of alarm 1, of a
AL. 1
sensor or a group of sensors that belong to a zone.
Indicates the number of active relays, related to exceeding the threshold of alarm 2, of a
AL. 2
sensor or a group of sensors that belong to a zone.
Indicates the number of active relays, relating to exceeding the alarm threshold 3, of a
AL .3
sensor or a group of sensors that belong to a zone.
INPUT
Indicates the number of active relay, LOGIC INPUT.
The screen can be closed by pressing
persist, the screen reappears after 10 minutes.
the screen will appear again automatically.
From the Main screen, by pressing
the sensors, displayed in groups of 6 at a time. Pressing
highlights the sensor in the first row. While, using the keys
to scroll through the sensors (in the page) shown on the display.
Pressing the
key again, you view the details of the highlighted
ENTER
sensor, (of course only if it is configured).
Explanations of the details are as follows:
st
1
row
Shows the number of the sensor (Gas Detector).
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
Low Charge
The detector is not Configured
The outputs (relay) are not activated if an alarm occurs.
Detector is disabling.
General information, of a faulty detector
There is no gas and there are no active alarms. The text blinks when
relay output is latched (Detector or Zone, returned to normality after an alarm or
a fault).
The first alarm threshold has been exceeded
The second alarm threshold has been exceeded
The third alarm threshold has been exceeded.
or
key.
ESC
RESET
If a new alarm occurs
and
keys, to scroll through
Discharge
Faulty or Disconnected
SETTINGSDATE and
ALARM STATUS
FAULT: 00
If the alarms
AL 2: 00
INPUT: 00
Press Reset/Esc
N. 1
GAS:
, key
ENTER
2 % LFL
and
ZONE:
OUTPUT
0 1
Pag. 17/52
Flashing =
TIME.
AL 1: 01
AL 3: 03
METHANE
5.60 mA
0
2
9
