90 AVENTICS | CMS, BDC, Stand-Alone | R412008961–BDL–001–AF
Disassembly, exchange, and extension
A
1
B
1
Fig. 18: Exchanging the module extension, for example R412008690 with 8 valve
outputs and D-SUB connection, CMS B-design bus coupler and VS (HF03 LG or
HF04) (A) or standalone system end plate (B)
1 Hexagonal socket-head screws M4
2 CMS end plate
3 Seal
4 (A): E end plate with VS HF03 LG or VS HF04;
(B): SAS end plate
7
6
5
2
7
3
6**
5
2
3
6*
4
3
3
6*
4
3
3
5 CMS B-design bus coupler
6 Tie rod
7 Module extension (here
R412008690 with 8 valve
outputs and D-SUB
connection)
**) *)
M4, M5
