AVENTICS | CMS, BDC, Stand-Alone | R412008961–BDL–001–AF
Bus coupler,
32 valves
Output 1
Output 1 + X1
Output 1 + X1 + X2
Output 1 + X1 + X2 + X3
Fig. 13: Signal distribution system
Table 6: Compatibility of module extensions, bus couplers and subbases for VS
HF04 and VS HF03 LG
Designation of
module extension
R412008691
1 x 16 with
D-SUB
R412008690
1 x 8 with
D-SUB
R412008692
4 x 2 with M8
R412008694
1 x M12 pin
1 x M12 socket
Output 1
Number of valves that
can be controlled
B Max. 16 single solenoid
valves or 8 double
solenoid valves
A Max. 8 single solenoid
valves or 4 double
solenoid valves
C Max. 8 single solenoid
valves or 4 double
solenoid valves
D Max. 2 single solenoid
valves or 1 double
solenoid valve
Output 1
Output 1
Compatible bus
couplers
Bus couplers CMC
and BDC B-type
75
Assembly
VS
Valve
position 1
solenoid 14
Compatible VS
W
HF04
W
HF03 LG
