Technical Data; Characteristics; Module Extension R412008690 With 8 Valve Outputs And D-Sub, 25-Pin - Aventics HF04 Mode D'emploi

AVENTICS | CMS, BDC, Stand-Alone | R412008961–BDL–001–AF
General
Protection class according to
ISO 20653/DIN VDE 0470 Part 1
Ambient temperature 
Continuous operation (S1) acc. to VDE 0580
Electromagnetic compatibility
Interference immunity
Interference emission
1)
With max. 3 modules
Electrical
1)
Operating voltage
Max. current per valve solenoid
Line length on D-SUB connector
1)
Functional voltage with safe isolation acc. to DIN EN 50178, classification VDE 0160
(power supply via bus coupler).
2)
See connected bus coupler.
3)
Observe the max. total current of the respective bus coupler.

10 Technical data

10.1 Characteristics

U
10.2 Module extension R412008690
with 8 valve outputs and D-SUB,
25-pin
3)
Technical data
IP 65 when assembled
-5C to +60°C without
condensation
EN 61000-6-2
EN 61000-6-4
100 mA
Max. 30 m
93
1)
1)
2)
...
