General Overview: Bus Coupler With Module Extensions And Vs Or As A Stand-Alone System - Aventics HF04 Mode D'emploi

62 AVENTICS | CMS, BDC, Stand-Alone | R412008961–BDL–001–AF
Device description
3
2
1
7
6
Fig. 1: Top: Example configuration with valve driver module, three module
extensions and installed VS (left) or end plate for Stand-Alone system (right)
Bottom: Example configuration with bus coupler, relay module and installed
VS (left) or end plate for Stand-Alone system (right)
1 BDC B-design bus coupler
2 Module extension 4x2 with M8
3 Module extension 1x16 with D-SUB
4 Module extension 1x8 with D-SUB
5 HF03 LG or HF04 series valve terminal
1)
With their own operating instructions.
5.1 General overview: Bus coupler
with module extensions and VS
or as a Stand-Alone system
The valve system consists of the following parts as
illustrated in Fig. 1: (depending on the order):
5
4
5
8
1)
3
2
1
7
6
6 E end plate
7 CMS B-design bus coupler
8 Module extension with relay function
9 SAS end plate
1)
10 Retaining bracket
(only BDC-B xxxxx-32 bus coupler)
9
4
9
8
1)
