AVENTICS | CMS, BDC, Stand-Alone | R412008961–BDL–001–AF
Module extension
1
Fig. 15: Labels on the module extensions
1 R412008690 and 8 valve outputs
with D-SUB connection
2 R412008691 with 16 valve outputs
and D-SUB connection

6.4 Labeling the module extension

O
Label the module extensions with the intended/used
address in the BTN field on the module connection side.
2
12
13
3 R412008692 with 4x2 valve outputs and
M8 connection
4 R412008694 with 2 outputs and relay
function
6.5 Connecting the modules
electrically
Applied electric voltage
Danger of injury from electric shock
O Make sure the relevant system component is not
under pressure or voltage before electrically
connecting modules to the valve terminal.
3
CAUTION
79
Assembly
4
