Specifications
Electrical
Supply Voltage:
Range:
Supply Frequency:
Supply Fuses:
Rated Input:
Mode of Operation:
Environmental
Operating Temperature Range:
Operating Humidity Range:
Operating Pressure Range:
Transport & Storage Temperature Range:
Transport & Storage Humidity Range:
Transport & Storage Pressure Range:

Replacing the External Fuses

1. Turn the program unit power switch off.
2. Disconnect the program unit from the power supply.
3. The program unit's fuse holder is located adjacent to the power switch on the rear of the top panel. Use a
small flat-head screwdriver to lift the lid of the fuse holder and pull the fuse holder from the chassis.
4. Remove each fuse by pulling it from its socket. Replace each fuse with a new fuse of the
appropriate specifications.
5. Reinsert the fuse holder in the program unit. Push the lid of the fuse holder in until the release snaps back
into position.
CAUTION: Replace each fuse with one of the correct specifications, as listed in Specifications.

Responsibility of the Manufacturer

Codman Sàrl accepts responsibility for the effects of safety, reliability, and performance of the equipment only if:
• Adjustments, modifications, and repairs are carried out by authorized personnel;
• The electrical installation of the relevant room complies with local regulations;
• The equipment is used in accordance with these instructions for use.

Safety Information

The CODMAN VPV System (catalog no. 82-3192) complies with the requirements of UL 60601-1, CSA-C22.2
No. 601.1-M90, EN 60601-1 and EN 60601-1-2.
WARNING: Equipment not suitable for use in the presence of FLAMMABLE ANESTHETIC MIXTURE
WITH AIR or WITH OXYGEN or NITROUS OXIDE.
CODFR10065zz10svn.indd 9 CODFR10065zz10svn.indd 9
100–240 VAC
90–264 VAC (Autodetected)
50/60 Hz
T5AL 250 VAC
100–240 VAC 6.5 A
Continuous with intermittent loading 30% maximum duty cycle
+10 °C to +35 °C
30% to 75% relative humidity, non-condensing
700 hPa to 1060 hPa
–40 °C to +60 °C
10% to 85% relative humidity, non-condensing
500 hPa to 1060 hPa

Service and Repair

Send the VPV System for service or repair to:
Codman Sàrl
Rue Girardet 29
Ch 2400 Le Locle
Switzerland
Always include a repair purchase order number and a written description of the problem.

End of Useful Life

Dispose of the equipment in accordance with local ordinances.

Warranty

Codman & Shurtleff, Inc., warrants that this medical device is free from defects in both materials and workmanship
for one (1) year from the date of purchase. Any other express or implied warranties, including warranties of
merchantability or fitness, are hereby disclaimed. Suitability for use of this medical device for any particular
surgical procedure should be determined by the user in conformance with the manufacturer's instructions
for use. There are no warranties that extend beyond the description on the face hereof.
® CODMAN, VPV, HAKIM, RICKHAM and SIPHONGUARD are registered trademarks of Codman & Shurtleff, Inc.

Appendix A: Confirming Valve Adjustment: Visually or by X-ray

Adjustment of the packaged valve can be confirmed visually or by x-ray. Adjustment of the implanted valve can be
confirmed by x-ray, if desired.
Figure 7 shows an x-ray of a CODMAN HAKIM Valve. The white marker on the valve indicates the right hand
side of the valve. The pressure indicator on the white ring indicates the chosen setting. If the valve were inverted,
the white marker would appear on the left side.
The positions of the pressure selection keys on the program unit's front panel also correlate with the positions of
the pressure indicator on the valve, as seen when x-rayed (Figure 8). The figure shows the location of the pressure
indicator for each setting (30 through 200). When the valve is adjusted to 70, 120, or 170, the pressure indicator
aligns with the "X" in the center of the valve.
The position of the pressure indicator of a packaged valve can also be observed visually. Figure 9 shows a
magnified view.
X-raying an Implanted Valve
Use an x-ray with intensifying TV screen, or an x-ray plate to confirm proper valve setting. Take care when
positioning the patient's head so that:
• the nonimplanted side of the head rests on the plate (the implanted side is uppermost from the plate), and,
• the inlet valve is parallel to the x-ray plate.
9
