5 Installation
5�9 Wiring Figure
CAUTION!
Connect the
connective cables to the
terminals, as identified,
with their matching
numbers on the terminal
block of the indoor
and outdoor units. For
example, Terminal L1(A)
A
of the outdoor unit must
connect with terminal
L1/1 on the indoor unit.
The outdoor unit can
match di erent types of
indoor unit, the numbers
on the terminal block of
the indoor unit may be
slightly different. Please
pay special attention
while connecting the wire.
Multi Split Type Air Conditioner / User Manual
42 / EN
