2 Overview
(A) Wall-mounted type
One-five
One-four
One-three
One-two
2�2 Controls and parts
Indoor unit
1. Panel frame
2. Rear air intake grille
3. Front panel
4. Air purifying filter & Air filter (behind)
5. Horizontal louver
6. LCD display window
7. Vertical louver
8. Manual control button (behind)
9. Remote controller holder
Outdoor unit
10. Drain hose, refrigerant connecting
pipe
11. Connective cable
12. Stop valve
13. Fan hood
Multi Split Type Air Conditioner / User Manual
(B) Duct/Ceiling type
One-five
One-four
One-three
One-two
Indoor unit
1. Air outlet
2. Air inlet
3. Air filter
4. Electric control cabinet
5. Wire controller
Outdoor unit
6. Drain hose, refrigerant connecting
pipe
7. Connective cable
8. Stop valve
9. Fan hood
4
17 / EN
