5 Installation
5�2 Installation Diagram
4
Remote
controller
Air filter
Remote
controller
CAUTION!
• To prevent wall damage,
use a stud finder to
locate studs.
• A minimum pipe run of
3 metres is required to
minimise vibration &
excessive noise.
• Two of the A, B, and C
A
air circulation pathways
must be free from
obstructions at all times.
• This illustration is for
demonstration purposes
only.
• The actual shape of
your air condtioner may
be slightly different.
• Copper lines must be
independently insulated.
Multi Split Type Air Conditioner / User Manual
3
Remote controller
Remote
controller
Remote
controller
5
One-Two
One-Three
One-Four
One-Five
Mounting screw
2
ST3.9 × 25-C-H
Air-break
Switch
holder
Air out
Mounting screw
ST3.9 × 25-C-H
1
More than 15cm
Installation plate
Clip anchor
Air-break Switch
1
2
Drainage
Pipe
5 4 3
Outdoor Unit
Power Cable
The maximum amount
of the connection
cables is 5.
This section is for
reference only.
(1)
More than 15cm
Installation plate
Clip anchor
Air filter
Refrigerant
pipe
Remote
controller
Remote
controller
holder
Air out
(2)
27 / EN
