2 Overview
(C)
Floor and standing type(console)
(C) Floor and standing type(console)
One-five
One-four
Indoor unit
1. Air flow louver (at air outlet)
2. Air inlet (containing air filter)
3. Remote controller
4. Installation part
5. Display panel
Outdoor unit
6. Drain hose, refrigerant connecting
pipe
7. Connective cable
8. Stop valve
9. Fan hood
18 / EN
One-three
One-twin
Multi Split Type Air Conditioner / User Manual
(D)
(D) Compact four-way cassette type
Compact four-way cassette type
One-five
One-four
One-three
One-twin
Indoor unit
1. Drain pump (drain water from
indoor unit)
2. Drain hose
3. Air outlet
4. Air inlet
5. Air-in grill
6. Display panel
7. Remote controller
Outdoor unit
8. Refrigerant connecting pipe
9. Connective cable
10. Stop valve
11. Fan hood
