76 AVENTICS | Position Controller | R412004397–BDL–001–AC
Technical Data
Creep speed version
Rapid speed version
Maximum mass
on the piston rod
Maximum counterforce
Precision
(based on entire stroke)
V at creep speed
max.
V at rapid speed
max.
Positioning time t
150
Standard strokes
Operating voltage
Power consumption
Compressed air quality
according to
ISO 8573-1:2010
Working pressure
Operating temperature range
Protection class according to
EN 60529/IEC 529
1)
The precision of the creep speed version is ±1.25%.
2)
t applies to positioning travel of up to 150 mm in the rapid speed version.
150
Time for longer positioning travel: t
Δs = positioning traveltot - 150 mm
v = current speed
All data was determined with rolling friction. Deviating operation conditions will influence function.

12.3 Positioning unit

Size I
525 762 1.. 0
525 762 2.. 0
30 kg
30 dN
±0.7%
50 mm/s
300 mm/s
 0.7 s
2)
50, 100, 150, 200
and 250 mm
Max. particle size: ≤ 50 μm
Oil content: 0 mg/m
The pressure dew point must be at least 15 °C below the ambient and
medium temperatures and must not exceed 3 °C.
= t + Δs/v
tot 150
Size II
525 764 1.. 0
525 764 2.. 0
80 kg
80 dN
1)
±0.5%
20 mm/s
250 mm/s
 2.0 s
24 V DC (±10%)
510 mA creep speed, 599 mA rapid speed
3
6 to 10 bar
5 °C to 50 °C
IP 65
Size III
525 766 1.. 0
525 766 2.. 0
180 kg
180 dN
±0.3%
12 mm/s
130 mm/s
 3.0 s
50, 100, 150, 200, 250,
300, 400 and 500 mm
