70 AVENTICS | Position Controller | R412004397–BDL–001–AC
Positioning unit adjustments
1 2 3 4 5 6
OPEN
Table 5:
Switches 1
7 8
ON
OPEN

10.3 Adapting to the special versions

To adapt the position controller to the special positioning unit
versions, you have to:
O
Plug the coding plug into a different socket.
O
Exchange the control for the solenoid valves (only for the
"voltage-free piston rod extension and reverse movement"
special version)
In the "voltage-free piston rod extension" special version,
the pneumatic connections are the opposite of those for the
"voltage-free piston rod retraction" version.
10.3.1
There are four jumpers each with two coding plugs on the
board.
1. See table 6 to find the number of the jumper that you have
to plug into a different socket in your special version.
Table 6:
Special version
"Voltage-free piston rod extension" rapid speed
"Voltage-free piston rod extension" creep speed
"Voltage-free piston rod retraction" creep speed
"Voltage-free piston rod retraction" rapid speed
"Voltage-free piston rod extension, reverse movement"
2. Using Fig. 12 or Fig. 13, identify the position of the jumper.
For all other versions (525 76X XXX 0)
2 3
X X X
Changing the coding plug on the board
4 5 6
X
X X
7 8
X X
Jumpers
1
2
3
4
5
