Design and applications

Fig. 1: Positioning system design

1 Positioning system

2 Positioning unit
3 Position sensor
4 Bottom
5 Cover
4 Design and applications
4.1 Positioning system
The positioning system consists of:
W
Position controller
W
Positioning unit
0 V
4
9
3
+ 10 V
5
6
7
8
10
6 Pneumatic cylinder
7 Valves
8 Position controller
9 Actual value
10 Set point
1
2
