74 AVENTICS | Position Controller | R412004397–BDL–001–AC

Technical Data

General data
Dimensions (width x height x depth)
Weight
Electrical connections
Operating temperature range
Storage temperature range
Protection class according to EN 60529/IEC529
Mounting orientation
Electronics
Operating voltage
Power consumption (without load at the outputs)
Output signals:
W
Connection terminals: 23, 24, 26, 27, 29, 31,
32, 34, 35 (valves)
W
Connection terminals: 17, 18
W
Connection terminals: 38, 39
(actual value output)
Input signals:
Set point:
W
Connection terminals: 13, 14
W
Connection terminals: 15, 16
W
Connection terminals: 13, 14, 17
Actual value:
W
Connection terminals: 11, 12
Permissible length of the connection cables for
valves, potentiometer, and set point
12 Technical Data

12.1 Position controller in a housing

102 mm x 140 mm x 25 mm
0.644 kg
Cage clamp terminals for 2.5 mm
5 °C to 50 °C
0 °C to 50 °C
IP 20 (device must be protected from moisture)
Any
24 V DC (±10%)
100 mA
24 V/600 mA
10 V/50 mA
0 to 20 mA (working resistance max. 500 Ω)
0 to 10 V (Ri = 1 MΩ)
0 to 20 V (Ri = 100 MΩ)
Potentiometer (approx. 5 kΩ)
0 to 10 V (Ri = 1 MΩ)
max. 30 m
2
line
