General data
Front plate dimensions (width x height)
Weight
Electrical connections
Operating temperature range
Storage temperature range
Protection class according to EN 60529/IEC529
Mounting orientation
Electronics
Operating voltage
Power consumption (without load at the outputs)
Output signals:
W
Connection terminals: d20, d22, d24, d26, z26
(valves)
W
Connection terminals: z12
W
Connection terminals: d2, z18
(actual value output)
Input signals:
Set point:
W
Connection terminals: d2, d16
W
Connection terminals: d14, d18
W
Connection terminals: d2, d16, z12
Actual value:
W
Connection terminals: d2, z6
Permissible length of the connection cables
for valves, potentiometer, and set point
AVENTICS | Position Controller | R412004397–BDL–001–AC

12.2 Position controller as a 19" assembly

100 mm x 160 mm (European size card)
128.4 mm x 25.4 mm (3 HU/5DU)
0.144 kg
DIN 4162 plug connector, form F,
32 connection terminals
5 °C to 50 °C
0 °C to 50 °C
IP 20
Any
24 V DC (±10%)
100 mA
24 V/600 mA
10 V/50 mA
0 to 20 mA (working resistance max. 500 Ω)
0 to 10 V (Ri = 1 MΩ)
0 to 20 V (Ri = 100 MΩ)
Potentiometer (approx. 5 kΩ)
0 to 10 V (R
max. 30 m
= 1 MΩ)
i
75
Technical Data
