Versions
Type SWR, socket reduced well
(7MC65..)
Type SWR, socket reduced well
(7MC55..)
SITRANS TS500 for installation in
existing protective tubes
Type GP, general purpose, no well
Table 9-5 Overview of SITRANS TSinsert dimensional drawings: measuring inserts for retrofitting and upgrading
Versions
European design
American design
SITRANS TSinsert/TS100/TS200/TS300/TS500 (7MC71.. 7MC72.. 7MC80.. 7MC75.. 7MC65.. 7MC55..)
A5E03920348-AB, 03/2016
Description
Temperature sensors for vessels and pipelines, socket well process
•
connection, tapered thermowell
SITRANS TS500, type SWR, socket reduced well (7MC65..) (Page 60)
•
Temperature sensors for vessels and pipelines, socket well process
•
connection, tapered thermowell
SITRANS TS500, type SWR, socket reduced well (7MC55..) (Page 61)
•
Temperature sensors for containers and pipelines, temperature sensors for
•
installation in existing protective sleeves, suitable for sleeves in accordance
with DIN 43772 and ASME B40.9-2001, with extension of European or
American design
SITRANS TS500 for installation in existing protective tubes (Page 62)
•
Temperature sensors for vessels and pipelines, threaded process connection,
•
no thermowell
SITRANS TS500, type GP, general purpose, no well (Page 63)
•
Description
Measuring inserts for temperature sensors, replaceable, mineral-insulated
•
version, European design (DIN ceramic base),
spring approx. 8 mm (0.31 inch)
SITRANS TSinsert - measuring inserts for SITRANS TS500 (Page 64)
•
Measuring inserts for temperature sensors, replaceable, mineral-insulated
•
version, American design, spring approx. 25 mm (0.98 inch)
SITRANS TSinsert - measuring inserts for SITRANS TS500 (Page 64)
•
