SAME AGROCOMPACT F60 Manuel D'atelier page 433

85
86
ITALAMEC 037
AN 1.5
85
C 1
V 1
N 2.5 N 1.5
N 1
N 1.5
2 1
4 3
AN 1.5
AN 1.5
VN 1
FAISCEAUX CABINE
87 87 85 87
30 86 30
ITALAMEC 037
AN 1 AN 1.5 AN 1
30 30
87 86 85 87
CB 1
87 87
A 1.5
L 1.5
PLANCHE 37 - FAISCEAU CONDITIONNEMENT D'AIR CABINE
87
AL FILTRO DISIDRATATORE
Dehydrator Filter
86
8
Installations
84
Système électrique
ALLA VENTOLA
Dehydrator Filter
A B A
TABELLA COLORI / COLOURS TABLE
M Marrone/Brown C Arancio/Orange
V Verde/Green A Azzurro/Blue
Z Viola/Violet B Bianco/White
N Nero/Black L Blu/Dark Blue
S Rosa/Pink G Giallo/Yellow
R Rosso/Red H Grigio/Gray
011.0644.3/20 tav.2
