8.2.2 The menu
After mains switching or plugging in the keypad during operation, the 10 codes defined to be the most
important in the user menu User (Code C0517) are available immediately.
In default setting the menu contains User all codes required for a standard application with linear V/f
characteristic control.
Code Name
C0050 Output frequency
C0034 Setpoint selection range
C0007 Fixed configuration of digital inputs
C0010 Minimum output frequency
C0011 Maximum output frequency
C0012 Acceleration time main setpoint
C0013 Deceleration time main setpoint
C0015 V/f rated frequency
C0016 U boost
min
C0002 Parameter set transfer/reset
Tip!
Use C0002 "Parameter set transfer" to easily transfer configurations from one controller to the other
or to reset the controller to Lenze settings.
L
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
- The 10 most important drive parameters
User
Lenze setting
Display: Output frequency without slip compensation
-0-
Standard I/O
Application I/O
-0-
0.00 Hz
50.00 Hz
5.00 sec
5.00 sec
50.00 Hz
depending on the inverter type
see code table ( 101)
Commissioning
Parameter setting using the keypad
X3/8: 0 ... 5 V / 0 ... 10 V / 0 ... 20 mA
X3/1U: 0 ... 5 V / 0 ... 10 V
X3/2U: 0 ... 5 V / 0 ... 10 V
E4 E3
CW/CCW DCB
CW/CCW rotation DC-injection brake
E2 E1
JOG2/3 JOG1/3
Selection of fixed setpoints
93
