Troubleshooting and fault elimination

Error messages

9.2

LEDs at the controller (operating status display)

LED
green red
on off
on on
blinking off
off blinking every second
off blinking every 0.4 seconds
fast blinking off
1)
Keypad PC Error
0 No fault
noer
71 System fault
ccr

61 Communication fault to AIF
ce0
(configurable in C0126)

62 Communication fault to
ce1
CAN-IN1 with Sync control

63 Communication error to
ce2
CAN-IN2

64 Communication error to
ce3
CAN-IN1 with event or time

control
65 BUS-OFF
ce4
(many communication faults

occurred)
66 CAN Time-Out
ce5
(configurable in C0126)

67 Function module system bus
ce6
(CAN) on FIF has set "Warning"

or "BUS-OFF"
(configurable in C0126)
68 Communication fault during
ce7
remote parameter setting via

system bus (C0370)
(configurable in C0126)
91 External fault (TRIP-SET)
EEr

- Communication abort between
ErP0
keypad and basic device
...
ErP19

95 E82ZMV fan module (only 8200
FAn1
motec 3 ... 7,5 kW)

TRIP or warning configurable
-
FAn1
under C0608
105 Internal fault
H05

108
EDK82EV903 DE/EN/FR 2.2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Operating status
Controller enabled
Mains switched on and automatic start inhibited
Controller inhibited
Fault active, check under C0161
Undervoltage switch-off
Motor parameter identification
Cause
-
Strong interferences on control cables
Ground or earth loops in the wiring
Faulty transmission of control commands via AIF
CAN-IN1 object receives faulty data or
communication is interrupted
CAN-IN2 object receives faulty data or
communication is interrupted
CAN-IN1 object receives faulty data or
communication is interrupted
Controller has received too many incorrect
telegrams via the system bus and has been
disconnected
For remote parameter setting via system bus
(C0370):
Slave does not answer. Communication monitoring
time exceeded.
For operation with application I/O:
Faulty parameter setting of parameter set
changeover
For operation with module in FIF:
Internal fault
CAN controller sets "Warning" or "BUS OFF"
Participant does respond or is not available
For operation with application I/O:
Faulty parameter setting of parameter set
changeover
A digital input assigned to the TRIP-Set function
has been activated.
Various
Fan module is defect
Fan module is not connected
Remedy
-
Shield control cables
Insert the communication module into the hand terminal
•
Plug-in connection - bus module
•
Check transmitter
•
Increase monitoring time under C0357/1 if necessary
•
Plug-in connection - bus module
•
Check transmitter
•
Increase monitoring time under C0357/2 if necessary
•
Plug-in connection - bus module
•
Check transmitter
•
Increase monitoring time under C0357/3 if necessary
•
Check whether bus terminator available
•
Check screen contact of the cables
•
Check PE connection
•
Check bus load, if necessary, reduce the baud rate
•
Check system bus wiring
•
Check system bus configuration
In all parameter sets the signal "parameter set
changeover" (C0410/13, C0410/14) must be combined
with the same source
Contact Lenze
•
Check whether bus terminator available
•
Check screen contact of the cables
•
Check PE connection
•
Check bus load, if necessary, reduce the baud rate
•
Check whether bus terminator available
•
Check screen contact of the cables
•
Check PE connection
•
Check bus load, if necessary, reduce the baud rate
In all parameter sets the signal "parameter set
changeover" (C0410/13, C0410/14) must be combined
with the same source
Check external encoder
Contact Lenze
Replace fan module
Connect fan module
Check wiring
Contact Lenze
Check FIF
Check FIF
Check FIF
L
