Guide d'installation
teleCARE IP
14
Kadex Interface Connection (Only for BENELUX)
Kadex support is only available for the Benelux and the Kadex equipment is not sourced by Ascom.
The Kadex Interface is an RF receiver that functions as a gateway between the Kadex RF network
and the Kadex server application.
The Kadex Interface receives data from various wireless Kadex sensors and it requires an ethernet
connection to forward the data towards the Kadex server application.
In order to reduce the installation costs in systems that consist of both Kadex and teleCARE IP
solutions, the room controller 3, from version 1.11.0 and up, can be connected to the Kadex
Interface via a USB connection. The Kadex Interface is powered directly from the NIRC3s power
source and will share the NIRC3s ethernet connection to relay the Kadex RF messages to and from
the Kadex server application.
Figure 428. Kadex Interface sharing the NIRC3s power and ethernet connection
AG
Figure 427. Kadex system overview
TD 92609FR
353
