en
5.6

Insulation

134
Installation
Case 2: access to motor fastening screws unrestricted.
▪ Carry out steps 1 to 4, 10 to 11 and 15 to 18 in sequence.
Steps 5 to 9 and 12 to 14 are not absolutely necessary.
Double pump
NOTICE
In general, rotate the motor head before the system is filled!
If you are forced to rotate one or both motor heads, undo the double pump cable con-
necting both control modules.
Carry out steps as described for the single pump:
Case 1: access to motor fastening screws restricted.
▪ Carry out steps 2 to 17 in sequence.
Case 2: access to motor fastening screws unrestricted.
▪ Carry out steps 2 to 3, 9 to 11 and 15 to 17 in sequence.
Steps 1, 4 to 8, 12 to 14 and 18 are not absolutely necessary.
Reconnect both control modules with the double pump cable. If required, loosen cable
loop by removing the cable retention clip.
Tightening torques for motor fastening screws
Screw
M6x18
M6x22
M10x30
Table 9: Tightening torques
Insulation of the pump in heating systems and domestic hot water circulation ap-
plications (only single pump)
WARNING
Hot surface!
The entire pump can become very hot. When retrofitting the insulation during nor-
mal operation there is a risk of burns!
Place both the half shells of heat insulation around the pump housing before commis-
sioning and press together. For this purpose, pre-install the four plastic dowels (scope
of delivery) in the drilled holes of one half shell.
Insulation of the pump in cooling/air-conditioning systems
NOTICE
The thermal insulation shells included in the scope of delivery are exclusively per-
mitted in heating and domestic hot water circulation applications with fluid temper-
atures > 20 °C!
Single pumps can be insulated for use in cooling and air conditioning applications using
Wilo cold water insulation shells (Wilo-ClimaForm) or any other commercially available,
diffusion-proof insulation materials.
There are no prefabricated cold water insulation shells for double pumps. For this pur-
pose, use commercially available, diffusion-proof insulation materials provided by the
customer.

Tightening torques [Nm]

8 – 10
8 – 10
18 – 20
WILO SE 2018-11
