Pre-defined applications in the settings assistant
• External control of the "External MAX" function through a binary input.
Drinking water accumulator – Charge pump ΔT
Drinking water accumulator – Accumulator charging temperature
Drinking water accumulator – Multi-Flow Adaptation
Drinking water – Differential pressure Δp-c
Drinking water – Differential pressure Δp-v
Drinking water – Index circuit Δp-c
Drinking water – Volume flow Q-const
Drinking water – Multi-Flow Adaptation
Drinking water – Temperature T-const
Drinking water – Temperature ΔT-const
Drinking water – Speed n-const
Differential pressure Δp-c
Differential pressure Δp-v
A variable differential pressure control is available for the application. Consumer loads
with connected consumers can be supplied with a variable differential pressure control
(Δp-v) according to the needs.
Assuming a maximum required delivery head at the design point, the pump variably ad-
justs the differential pressure to the volume flow. The volume flow varies through the
open and closed valves at the consumers. The pump output is adjusted to the require-
ments of the consumer load and the energy requirement is significantly reduced.
Index circuit Δp-c
A constant differential pressure control is available for the "Index circuit Δp-c" applica-
tion. This differential pressure control ensures supply in a poorly compensated hydraulic
system.
The pump takes into account the point in the hydraulic system which is the most difficult
to supply.
For this purpose, the pump requires a differential pressure sensor which is installed at this
point in the system.
The delivery head must be adjusted to the required differential pressure at this point and
the pump output is accordingly adjusted to the requirements of the consumer loads there.
Dynamic Adapt plus
Volume flow Q-const
Multi-Flow Adaptation
172
Setting the control functions
Available additional control functions
‣ Q-Limit
Max
• Fixed activation addition control func-
tion:
‣ Q-Limit
Min
‣ Q-Limit
Max
• Fixed activation addition control func-
tion:
‣ Q-Limit
Min
No additional control functions
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
No additional control functions
‣ Q-Limit
Min
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
‣ Setback operation
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
‣ Setback operation
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
‣ Setback operation
‣ No-Flow Stop
‣ Q-Limit
Max
‣ Q-Limit
Min
‣ Setback operation
‣ Setback operation
‣ No-Flow Stop
‣ Setback operation
‣ No-Flow Stop
