Installation and operating instructions Wilo-Stratos MAXO/-D/-Z
Put into operation
Select type of use
Analogue input (AI2)
Not configured
Setpoint controller
Differential pressure sensor
Temperature sensor
External sensor
Fig. 40: Settings dialogue
NOTICE
Press the operating button without selecting another parameter or adjusting an-
other value to confirm the setting.
Press the Back button to discard the current adjustment and retain the previous
setting. The menu changes to the previous setting or previous menu.
NOTICE
Pressing the context button
further settings.
Status area and status displays
The status area is located on the left side above the main menu area
"Home screen" figure and table).
If a status is active, it is possible to display and select status menu items in the main
menu.
Turn the operating button to the status area to show the active status.
If an active process (e.g. venting process) is quit or discarded, the status display is hid-
den again.
Settings
1.1
Set auto control
Settings assistant, setpoints, options
Manual operation
Manual override
Double pump operation
Set double pump
External interfaces
Analogue, digital, SSM, SBM
Fig. 41: Main menu status display
There are three different classes of status displays:
1. Display process:
Set analogue input
as setpoint controller,
e.g. for delivery head
will display additional context-related options for
Overriding
auto control via
manual intervention.
en
1.1
. (See also
155
