Installation and operating instructions Wilo-Stratos MAXO/-D/-Z
Setting the control functions
Application
Heating
Cooling
Heating & cooling
Drinking water
Basic control modes
Fig. 45: Application selection
The "Heating" application is used as an example.
Application
Heating
Cooling
Heating & cooling
Drinking water
Basic control modes
Fig. 46: Example – "Heating" application
Select the "Heating" application by turning the operating button and press to confirm.
Different system types are available depending on the applications.
The following system types are available for the "Heating" application:
System types for heating application
‣ Radiator
‣ Underfloor heating
‣ Ceiling heating
‣ Fan heater
‣ Hydraulic shunt
‣ Heat exchanger
‣ Basic control modes
The "Radiator" system type is used as an example.
en
Menu for adjusting
pump functions
The pump is used to
supply heat.
Settings help
