Danger of burns caused by hot valve coils!
Touching the valve coils during operating may lead to burns.
Let the device cool off before disassembling it.
Do not touch the device during operation.
AVENTICS
8.1

Selecting the correct supply pressure

A permanet deviation will occur if the supply pressure is less than
the outlet pressure stipulated by the electrical set point. The
electronics will reduce the power consumption and thus the max.
nominal width to prevent the ED07 pressure regulator from
heating up.
CAUTION
Always select a supply pressure that is higher than the outlet
pressure.

8.1.1 "Pressure reached" switch output

The "Pressure reached" switch output is only available in
"ED07 pressure regulator with integrated
integrated X2M socket, M12" devices.
The ED07 pressure regulator with integrated
integrated X2M socket, M12, recognizes whether the desired outlet
pressure is set within a tolerance of 200 mbar.
The switch output at pin 1 in the integrated
switches to a value that is the same as the supply voltage or 2.0
volts smaller (high level), as long as the actual value is within the
set point tolerance range of 200 mbar.
If the actual value is outside the tolerance range, the switch output
has a voltage of < 2.0 V DC (low level).
This signal can be used e.g. by the controller to enable additional
process steps.
| ED07 | R41400766–BDL–001–AB
Controlling the ED07 pressure regulator
X1S
X1S
X2M
65
plug, M12, and
plug, M12, and
socket, M12,
