50 AVENTICS | ED07 | R41400766–BDL–001–AB
Device description
This ED07 pressure regulator model is available for the following
outlet pressures:
Table 2: : ED07 pressure regulator with integrated
Order number
R414000686
R414000690
R414000691
R414000700
R414000701
R414000785
R414000786
Outlet pressure Set point
–1 to +1 bar 0 to 20 mA
0 to 6 bar 0 to 20 mA
0 to 6 bar 4 to 20 mA
0 to 10 bar 0 to 20 mA
0 to 10 bar 4 to 20 mA
0 to 20 bar 0 to 20 mA
0 to 20 bar 4 to 20 mA
XPC
plug, M12
Actual value
0 to 20 mA
0 to 20 mA
4 to 20 mA
0 to 20 mA
4 to 20 mA
0 to 20 mA
4 to 20 mA
