Ed07 Pressure Regulator With Two Rectangular Plugs - Aventics ED07 Mode D'emploi

16
12
11
10
9
Fig. 3: ED07 with two
1 Calibration port cap
2 Housing ventilation port
3 Valve solenoids
4 Exhaust port
5 Supply pressure port
6 Coded hole
7 Mounting pins for base plate seal
8 Outlet pressure port
5.3 ED07 pressure regulator with two
rectangular plugs
17
3
X1S and X2A rectangular plugs, DIN EN 175301-803
AVENTICS | ED07 | R41400766–BDL–001–AB
12
1
4
8
18
9 M5x90 screws (DIN EN ISO 4762, formerly
DIN 912)
10 Base plate seal
11 Housing seal
12 Housing cover mounting screw
16 X1S rectangular plug
17 X2A rectangular plug
18 Rectangular plug connector
Device description
2
3
5
6
7
53
00121358
