AVENTICS | AS1 / AS2 / AS3 / AS5 | R412013437–BAL–001–AH | English
W
Do not modify or convert the product.
W
Persons who assemble, operate, disassemble,
or maintain AVENTICS products must not consume any
alcohol, drugs, or pharmaceuticals that may affect
their ability to respond.
W
The warranty will not apply if the product is incorrectly
assembled.
W
Do not place any improper mechanical loads on the
product under any circumstances.
W
Product warnings and information must be legible,
i.e. not covered by paint, etc.
Safety instructions related to the product
and technology
W
Lay cables and lines so that they cannot be damaged
and no one can trip over them.
W
Do not operate the product in aggressive ambient air
or allow it to come into contact with aggressive media.
The substances listed as examples in the following
table, which contain solvents in various
concentrations, can lead to an aggressive ambient air/
compressed air in the application area of compressed
air preparation devices and in the suction area of air
compressors.
Solvents: Acetone, paint thinners, alcohols, ester
Detergents: Trichloroethylene, perchlorethylene,
benzene, gasoline
Other media: Synthetic oils, drilling oil, high-alloyed oils,
certain compressor oils, brake fluid,
ammonia, bonding and sealing agents,
plasticizers, anti-freeze, coolants/
lubricants
A pressurized polycarbonate reservoir may corrode
in an aggressive ambient air/compressed air and
explode as a result.
If the presence of the substances stated in the table
cannot be avoided, such as in gluing machines or
vulcanization plants, the use of metal reservoirs
is required.
W
No soiling may be allowed to collect on or in the filters,
reservoirs or windows. Replace reservoirs if soiling
cannot be removed from the drain (drain may become
clogged).
Also observe the "Customer information on material
resistance in compressed air preparation"
(MNR R412025273).
3

Delivery Contents

The delivery contents include:
W
1 lubricator as ordered
W
Operating instructions
4

About This Product

1
Lubricators are components of maintenance units.
They are used to meter and dispense oil to compressed
air. Typical implementation areas include cylinders with
speeds > 1 m/s, metallic sealing valves and pneumatic
tools.
5 Assembly, Commissioning
and Operation
O Let the product acclimatize for several hours before
commissioning, otherwise, water may condense
in the housing.
Danger of injury if assembled under pressure
or voltage!
Assembling when under pressure or electrical voltage
can lead to injuries and damage to the product
or system components.
O Make sure that the relevant system part is not
under voltage or pressure before you assemble
the product.
O Protect the system against being switched on.
Sudden rise in pressure during commissioning!
The system is exposed to sudden pressure on
commissioning if no SSU filling unit is used! This may
result in dangerous erratic cylinder movements.
O Please ensure when commissioning a system
without a SSU filling unit that the cylinders are
in their end position or that no danger can emit
from those not in end position.
System is operating under pressure!
Incorrect installation may damage the maintenance
unit/apparatus and cause serious injury.
O Before commissioning, check that all connections,
ports and maintenance equipment have been
correctly installed.
CAUTION
