AVENTICS | RG1 | R412020031–BDL–001–AB | English
English
1

About This Documentation

These instructions contain important information for the safe and appropriate
assembly and commissioning of the product.
O Read these instructions carefully, especially the section
"Notes on Safety", before working with the product.
Required and supplementary documentation
The RG1 pressure regulator is a system component.
O Also follow the instructions for the other system components.
O Furthermore, observe general, statutory and other binding rules of the European
and national laws.
Presentation of information
Warnings
In this document, there are warning notes before the steps
whenever there is a danger of personal injury or damage to equipment. The
measures described to avoid these hazards must be observed.
Structure of warnings
Hazard type and source
Consequences of non-observance
O Measures to avoid these hazards
Meaning of the signal words
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injuries.
Indicates that damage may be inflicted on the product or the environment.
Symbols
Operation may be impaired if this information is disregarded.
2 Notes on Safety
The product has been manufactured according to the accepted rules of current
technology. Even so, there is a risk of injury or damage if the following general safety
instructions and the specific warnings given in this instruction manual are not
observed.
O Read these instructions completely before working with the product.
O Keep these instructions in a location where they are accessible to all users at all
times.
O Always include the operating instructions when you pass the product on to third
parties.
Intended use
O Use the pressure regulator only to reduce the applied system pressure to a
maximum, regulated working pressure.
O Only use compressed air as the medium.
O Use is permitted only under the operating conditions and within the performance
limits listed in the technical data.
O The pressure regulator is for industrial applications only.
Personnel qualifications
All tasks associated with the products require basic mechanical and pneumatic
knowledge, as well as knowledge of the respective technical terms. In order to
ensure operational safety, these tasks may only be carried out by qualified personnel
or an instructed person under the direction of qualified personnel.
Qualified personnel are those who can recognize possible hazards and institute the
appropriate safety measures, due to their professional training, knowledge, and
experience, as well as their understanding of the relevant conditions pertaining to
the work to be done. Qualified personnel must observe the rules relevant to the
subject area.
General safety instructions
W
Observe the valid local regulations to protect the environment in the country of
use and to avoid workplace accidents.
W
Only use AVENTICS products that are in perfect working order.
W
Examine the product for obvious defects, such as cracks in the housing or
missing screws, caps, or seals.
W
Do not modify or convert the product.
SIGNAL WORD
CAUTION
NOTICE
W
Do not place any mechanical loads on the product under any circumstances.
W
The warranty will not apply if the product is incorrectly assembled.
W
Product warnings and information must be legible, i.e. not covered by paint, etc.
Safety instructions related to the product and technology
W
Lay cables and lines so that they cannot be damaged and no one can trip over
them.
W
Do not operate the product in aggressive ambient air
(e.g., solvent vapors).
3

Delivery Contents

The delivery contents include:
W
1 pressure regulator
W
Operating instructions
4

About This Product

Pressure regulators serve to reduce the applied system pressure to a maximum,
regulated working pressure.
1 Overview of pressure regulator
1 Working-pressure connection (IN)
2 Regulated-pressure connection (OUT)
3 Knurled screw for setting the working
pressure
Product identification
Observe the product information on the product and packaging.
5 Assembly, Commissioning, Operation
Danger of injury if assembled under pressure!
Assembling when under pressure can lead to injuries and damage to the product
or system components.
O Make sure that the relevant system part is not under pressure before you
assemble the product.
O Protect the system against being switched on.
System is operating under pressure.
Incorrect assembly could damage the pressure regulator or the system and
cause serious injury.
O Before start-up, check that all connections to the pressure regulator have
been assembled correctly.
1 Assembling the pressure regulator and connecting
pneumatically
Danger of contaminating the pressure regulator
Dirt particle deposits can compromise the regulation function or damage the
pressure regulator.
O Blow out all compressed air lines before assembly.
O Use an upstream particle filter of at least 50 μm.
O Install the pressure regulator such that the air flows in the direction of
the arrows on the housing (IN to OUT). This is the only way to ensure
proper regulator function.
1. Make sure that the system is not under voltage or pressure.
2. Connect the pressure regulator to the pressure system.
During installation, check the flow direction at the pressure regulator (IN =
working pressure connection, OUT = regulated pressure connection).
1 Setting the pressure
W
Turning the knurled screw (3) clockwise increases the output pressure.
W
Turning the knurled screw (3) counterclockwise decreases the output pressure.
4 Base screw
5 Valve seat
CAUTION
NOTICE
