PC setup program
Digital signals:
A binary signal associated with two plain texts. Depending on the binary value of each one
of the two plain texts is displayed. Example: A manual / automatic switch is to be
visualised. Depending on the position of either the text "Manual mode" or "automatic
mode" is displayed.
Configuration item
Visible
X position
Y-position
Width
Height
Digital signal
Background colour
Transparent
Frame shape
Colour for low
Text for low
Colour for high
Text for high
Font size
Alignment
Item type
417102269 Rev. 2-08.2020
Selection / option
Check marks
0-315 pixels
0-181 pixels
1-316 pixels
1-182 pixels
Selection from the analogue
selector
Select colour palette
Check marks
None
thin
thick
deepset
Select colour palette
12/13/15/24/33/37/48/64
pixels
Left justified
right justified
centred
Horizontal
vertical
Auto,
fixed-point format
Left justified
centred
right justified
Horizontal
vertical
230
Explanation
Checking the box: Object appears, blank check
box: Object hidden
X-coordinate of the upper left corner of the icon
Y coordinate of the upper left corner of the icon
Size of the analogue display
Binary signal source of digital display
Background fill of the analogue display
Excluding the background fill, only the numerical
display is visible
Select a frame format
Font colour for binary value = 0
Text in binary value = 0
Font colour for binary value = 1
Text in binary value = 1
Font size of the numeric display
Font orientation of the digital display
Orientation of the analogue display
