To connect the bus coupler load supply:
1. Set up the correct pin assignment (see Table 7 on page 80
2. Connect the bus coupler operating voltages using the socket
3. Check the operating voltage specifications using the
4. Provide power according to Table 8, page 81. Select the
5.3.6
Freely accessible conductive parts
Risk of electric shock on contact!
O
Input module 1. Wire the inputs according to Table 11 (8DI_M8) or Table 12
2. Connect the electrical inputs/outputs to the I/O modules
3. To ensure the IP 65 protection class, close unused sockets
AVENTICS | PROFINET-IO | R412015162–BDL–001–AE
or see Table 9 on page 81) on the plug connections if you are
not using pre-assembled cables.
coupling (see "Spare parts and accessories" on page 112).
electrical characteristics and comply with them (see chapter
"Technical Data" on page 110).
cable cross-section according to the cable length and
occurring currents.

Connecting the 8x input/output modules

When connecting peripheral devices (I/O interface),
observe the requirements to protect against accidental
contact in accordance with EN 50178, classification
VDE 0160.
(8DI_M12).
with M8 or M12 coupling plugs (accessories).
with M8 or M12 protective caps (accessories).
The total current for all sensor supplies (pin 1) on one valve
system must not exceed 0.7 A.
On delivery, all diagnostic messages are deactivated,
i.e. all DIP switches are set to OFF.
All tolerance settings are set to ON (10%)
CAUTION
83
Assembly
