AVENTICS | EtherCAT | R412012792–BDL–001–AB
Fig. 4: Label areas on the bus coupler
6.3 Connecting the bus coupler
electrically
Applied electric voltage
Danger of injury from electric shock
O Make sure the relevant system component is not
under pressure or connected to power when
electrically connecting modules to the valve
terminal.
CAUTION
59
Assembly
