The high-pressure gun is not working properly
Illustration T
An internal error has occurred in the electronics of the
high-pressure gun.
1. Press the locking slide.
Illustration Q
2. Open the battery compartment.
3. Remove the battery.
4. Insert the batteries, paying attention to the correct
alignment of the poles.
5. Close the battery compartment.
Have the high-pressure gun checked by Customer
Service if this fault occurs repeatedly.
Warranty
The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing flaw is the cause. In a warranty case, please con-
tact your dealer (with the purchase receipt) or the next
authorised customer service site.
(See overleaf for the address)
Further warranty information (if available) can be found
in the service area of your local Kärcher website under
"Downloads".
Technical data
Electrical connection
Voltage
Phase
Frequency
Maximum permissible
mains grid impedance
Power rating
Degree of protection
Protection class
Power protection (slow-
blowing)
Water connection
Feed pressure (max.)
Input temperature (max.)
Input amount (min.)
Suction height (max.)
Device performance data
Operating pressure
Max. permissible pressure MPa
Water flow rate
Maximum flow rate
Detergent flow rate
High-pressure gun recoil
force
Dimensions and weights
Typical operating weight
20
K 7 Smart Premium
Control Smart
Flex Control
Flex
V 230 230
~ 1 1
Hz 50 50
©
0,394+ 0,394+
j0,246 j0,246
kW 3,0 3,0
IPX5 IPX5
I I
A 16 16
MPa 1,2 1,2
°C 60 60
l/min 12 12
m 0,5 0,5
MPa 15 15
18 18
l/min 9,2 9,2
l/min 10 10
l/min 0,3 0,3
N 27 27
kg 19,3 19,8
Length
Width
Height
Radio module SRD
Frequency
Transmitting power ERP
Bluetooth radio module
Frequency
Transmitting power ERP
Determined values in acc. with EN 60335-2-79
Hand-arm vibration value m/s
Uncertainty K
Sound pressure level L
Uncertainty K
pA
Sound power level L
uncertainty K
WA
Exception according to Regulation (EU) 2019/1781 An-
nex I Section 2 (12): j)
Subject to technical changes without notice.
EU Declaration of Conformity
We hereby declare that the product named below com-
plies with the relevant provisions of the directives and
regulations listed. This declaration is invalidated by any
changes made to the product that are not approved by
us.
Product: High-pressure cleaner
Type: 1.317-xxx K 7 (Premium) Smart Control
Directives and Regulations
2006/42/EC (+2009/127/EC)
2014/53/EU
2011/65/EU
2000/14/EC
2009/125/EC
Commission Regulation(s)
(EU) 2019/1781
Harmonised standards used
EN 60335-1
EN 60335-2-79
EN 62233: 2008
EN 300 220-2 V3.1.1
EN 300 328 V2.2.2
EN IEC 63000: 2018
Applied conformity evaluation method
2000/14/EG: Annex V
Sound power level dB(A)
Measured: 92
Guaranteed: 95
Name and address
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Tel.: +49 7195 14-0
Fax: +49 7195 14-2212
English
K 7 Smart
Control
Flex
mm 458
mm 330
mm 669
MHz 868,7-
869,2
mW 0,53
GHz 2,45
mW 6,3
2
1,3
2
m/s 0,6
dB(A) 79
pA
dB(A) 3
+ dB(A) 95
WA
Premium
Smart
Control
Flex
459
330
669
868,7-
869,2
0,53
2,45
6,3
1,3
0,6
79
3
95
