may only be performed at washing stations with an oil
separator.
Working with detergents may only be performed on
watertight surfaces with connection to the waste
water sewage system. Do not allow detergent to enter
waterways or the soil.
Extraction of water from public waterways is not
permitted in some countries.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.de/REACH
Intended use
Use the high-pressure cleaner in private households
only.
The high-pressure cleaner is intended for cleaning ma-
chines, vehicles, buildings, tools, façades, terraces,
garden machines etc. using a high-pressure water jet.
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.
Description of the device
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the illustrations, refer to the graphics page
Illustration A
Illustration B
Stand with carrying handle
1
Water connection with integrated sieve
2
Transport wheel
3
Hose guide
4
Trigger "0/OFF" / "I/ON"
5
Storage for spray lance
6
High-pressure hose
7
*Plug 'n' Clean detergent bottle
8
Storage / parking position for high-pressure gun
9
3-in-1 multi-jet spray lance with 3 spray types (see
10
also chapter Smart Control System)
Smart Control high-pressure gun
11
LCD display (see also chapter LCD display)
12
Battery compartment lock
13
Battery compartment
14
"+/-" buttons for pressure control
15
High-pressure gun lock
16
Button for separating the high-pressure hose from
17
the high-pressure gun
High-pressure gun lever
18
Transport handle, telescoping
19
Carrying handle
20
Hose holder
21
High pressure hose reel
22
Crank handle for hose reel
23
Type plate
24
Accessory compartment
25
Hook for net attachment
26
Accessory compartment net
27
Mains connection with mains plug
28
Water connection coupling
29
**Garden hose (fabric reinforced, diameter at least
30
1/2 inch (13 mm), length at least 7.5 m, with com-
mercially available quick coupling)
**KÄRCHER suction hose for water supply from
31
open containers (order no. 2.643-100.0)
* optional, ** additionally required
Illustration C
Area of application (1-SOFT / 2-MEDIUM / 3-HARD
1
with 2 pressure levels each)
BOOST function indicator
2
Spray type recommendation (flat stream/detergent/
3
dirt blaster)
Display Bluetooth
4
Signal strength status (four levels)
5
Battery status (empty, almost empty, medium, full)
6
Detergent level (1 / 2 / 3)
7
For the illustrations, refer to the graphics page.
Fit the supplied loose parts onto the device before start-
ing up the device.
Have the included screws and the appropriate screw-
driver ready.
Mounting the accessory net
1. Hang the accessory net on the hooks.
Illustration D
Push the high-pressure hose through the
1. Insert the high-pressure hose through the hose
guide from the rear.
Illustration E
Installing the water connection coupling
1. Screw the water connection coupling onto the water
connection on the device.
Illustration F
English
LCD display
®
connection
Installation
hose guide
15
