ULTRAFLEX
3.6 Type of installation
The UC128-OBF hydraulic cylinder for outboard engines can be installed with different configurations according to
the number and the type of engines used with a single or dual steering system. The possible configurations are:
CAUTION
Connect hoses as shown in the following pictures:
SINGLE STATION / SINGLE CYLINDER:
1
2
4
1. helm
2. starboard cylinder
3. "T" fittings
4. kit OB
DUAL STATION / SINGLE CYLINDER:
1
2
5
6
6
6
6
1. upper station helm
2. lower station helm
3. starboard cylinder
4. "T" fittings
5. kit OB-2S
6. kit OB
page 22
of 103 -
HYDRAULIC CYLINDER FOR OUTBOARD ENGINE
3
4
3
4
Installation and Maintenance Manual
SINGLE STATION / DUAL CYLINDER:
7
2
5
8
1
1. helm
2. starboard cylinder
3. port cylinder
4. "T" fittings
DUAL STATION / DUAL CYLINDER:
1
3
9
6
10
10
2
10
10
1. upper station helm
2. lower station helm
3. starboard cylinder
4. port cylinder
5. "T" fittings
6
3
4
8
5. "T" fittings
6. tie bar
7. kit OB-2C
8. kit OB
7
4
5
8
6. "T" fittings
7. tie bar
8. kit OB-2C
9. kit OB-2S
10. kit OB
