ULTRAFLEX
1.3 Configurations
The hydraulic cylinder for outboard engine UC128-OBF model can be installed with different configurations ac-
cording to the number and the type of engines used with a single or dual engine steering system.
The possible configurations are:
STEERING STATION NUMBER
S
I
N
G
L
E
S
T
A
T
I
O
N
D
MAIN STATION
U
A
L
ADDITIONAL
STATION
S
T
A
T
I
O
N
NOTICE
On request, triple outboard engine applications are available. For detailed information, please contact ULTRAFLEX
Assistance Service.
DANGER
Dual engine installations require the use of a tie bar.
page 10
of 103 -
HYDRAULIC CYLINDER FOR OUTBOARD ENGINE
S
I
N
G
L
E
E
N
G
I
N
E
With SINGLE STANDARD CYLINDER (starboard version)
D
U
A
L
With SINGLE STANDARD CYLINDER ( starboard version )
E
N
G
I
N
E
With DUAL CYLINDER (starboard + port)
Installation and Maintenance Manual
ENGINE NUMBER
up to 300hp max or
up to 55 m.p.h.
non-counter rotating en-
gines up to 300 hp max of
combined horsepower or
up to 55 m.p.h.
counter rotating engines
up to 500 hp max of com-
bined horsepower or up
to 55 m.p.h.
and TIE BAR
non-counter rotating en-
gines up to 500 hp max of
combined horsepower or
up to 55 m.p.h.
counter rotating engines
up to 600 hp max of com-
bined horsepower or up
to 65 m.p.h.
