Installations- och bruksanvisning Rocher Pure
2.20.
Principskiss när styrcentral Pure
Agregat
Adapterkretskort
OLEA 99
Agregat
Sensorkabel
1 = Blå
Adapterkretskort
2 = Vit
OLEA 99
3 = Röd
4 = Gul
A1 Gul
A2 Grön
A3 Röd
A4 Svart
Principskiss
Sensor OLET 31
Silikon 4 x 0,25 mm²
Aggregat
Bild 10 Principskiss
Begränsare
Kopplingsribba
4
3
2
1
Sensor OLET 31
Styrcentral
Pure
Dörrkontakt
1601 - 33
Styrcentral
Pure
1601 - 33
4 x 0,15 mm²
Inneffekt
230V – 240V 1N~ / 2~
230V 3~
400V – 415V 3N~
14
OBS!
För utförligare
installationsanvisningar
se styrcentralens
.
bruksanvisning
