You will need to adjust your chair from time to time for best performance (especially if you
alter the original settings). This chart gives you a first solution, then a second and a third if
needed. You may need to look farther to find the best solution for a specific problem.
NOTE– To keep track of your progress, make only ONE change at a time.










931135 Rev. A
E n g l i s h
XI. TROUBLESHOOTING
SOLUTIONS
Make sure tire pressure is correct and equal in both rear tires and
front caster tires, if pneumatic.

Make sure all nuts and bolts are snug.
Make sure all spokes and nipples are tight on radial spoke wheels.
Use Tri-Flow Lubricant (Teflon™-based) between all modular frame
connections and parts.

Check for proper caster plate adjustment. See instructions for caster
plate adjustment.
Add a spacer washer between the plastic saddle and the caster
plate on the top of the left caster plate.
Add a spacer washer between the plastic saddle and the caster
plate on the top of the right caster plate.
Add a spacer washer between the plastic saddle and the caster
plate on the bottom right caster plate retaining bolts.
Add a spacer washer between the plastic saddle and the caster
plate on the bottom left caster plate retaining bolts.

Make sure both front casters touch the ground simultaneously. If
they do not, add the proper spacers between the bottom bearing
of the caster plate and fork stem nut until they do. Make sure you
check for this problem on a flat surface.
