X . V e n t a n d B a t t e r y T r a y
Vent and Battery Tray
Figure A
Rear strut shown in
Position 14
Center Strut shown
in Position 5
Roller Assembly
shown in Position 3
Front strut shown in
Position 1
Front caster bracket
shown in forward
orientation
Vent and Battery Tray
Figure B
E n g l i s h
Rear axle plate
Shown in
Position 15
