DESCRIPTION
Fig 1a.
1. Lower vacuum tube
2. Vacuum bag
3. Adaptor
4. Cruise control
5. Throttle trigger
6. Upper vacuum tube
7. Fuel cap
8. Starter grip
9. Starter lever
10.Upper handle
11.On/off switch
12.Positive switch at blowing side
13.Primer bulb
14.Vacuum handle
Fig 1b
15. Upper blower tube
16. Door tab
17. Inlet cover door
18. High velocity nozzle with leaf scraper
19. Positive switch at vacuuming side
Fig 2
15. Upper blower tube
18. Lower blower tube
19. Positive switch at vacuuming side
Fig 3
2. Vacuum bag
3. Adaptor
Fig 4
20. Raised slot
21. Adaptor installed in vacuum bag
22. Raised locking tab with switch insert metal plate
Fig 5
23. Vacuum bag assembly
24. Screw on Inlet cover
25. Vacuum Inlet cover tab
17. Inlet cover
19. Positive switch at vacuuming side
Fig 6
26. Vacuum opening
27. Locking tab
28. Vacuum tube assembly
29. Screw for holding vacuum tube assembly
17. Inlet cover
19. Positive switch at vacuuming side
Fig 7
8. Starter grip and rope
IT PT NL SV DA
English(Original instructions)
NO FI HU CS RU
30. Quick start label
5. Throttle trigger
11. On/Off switch
9. Start lever
13. Primer bulb
Fig 8
12. Positive switch at blowing side
19. Positive switch at vacuuming side
Fig 9
31. High velocity nozzle
Fig 10
4. Cruise control
5. Throttle trigger
Fig 11
12. Positive switch at blowing side
19. Positive switch at vacuuming side
Fig 12
32. Air filter cover
33. Turn the dial to open and close
Fig 13
32. Air filter cover
34. Air filter
FEATURES
PRODUCT SPECIFICATIONS
Engine Displacement................................................ 26cc
Air Velocity .........................................................320 Km/h
Air volume.........................................................11 m 3 /min
Weight .................................................................... 4.3 kg
Rated power ........................................................... 0.6Kw
Engine speed (Max.) .........................................9000 rpm
Engine speed (Idle.) ...............................3000 – 4600rpm
Sound power level according to EN 15503:2009 Annex
A(Blower/vaccum)
Racing ...................................................83.3 / 82.8 dB(A)
Idling ......................................................72.4 / 71.1 dB(A)
Equivalent A-weight emission sound pressure level
...............................................................83.3 / 82.8 dB(A)
Sound pressure level at operator position(Blower/
vaccum)
Racing ...................................................96.4 / 96.6 dB(A)
Idling ......................................................81.3 / 81.6 dB(A)
Equivalent A-weight emission sound pressure level.........
...............................................................88.7 / 88.9 dB(A)
Uncertainty of sound level measurement .............3 dB(A)
vibration value at handle according to EN 15503:2009
Annex B
Blower mode(Front handle/ rear handle)
Racing .....................................................1.63 / 1.57 m/s
15
