4 - GENERAL
4.7
KEYBOARDS
In place of the encoder, the value of essential parameters such as temperature, time, humidity and core temperature can be easily entered using the
keyboard by selecting the appropriate icon opposite the field to be filled in.
These keyboard pop-ups are configured according to the specific parameters to be set, allowing precise customisation of the keyboard.
4.7.1
CAVITY COOKING TEMPERATURE
Using the keypad to set the cavity cooking temperature is simple and intuitive.
When you first press the keypad opposite the temperature zone, a pop-up appears showing nine pre-set temperature keys. By pressing one of these
keys, the corresponding temperature is displayed in the temperature zone.
These values represent customer profile parameters, offering flexible customisation of cooking temperatures. Only previously entered values are
visible, arranged in ascending order. Users can modify or delete existing keys to adapt the keypad to their specific needs.
Deleting a pre-registered key
» Press the key you want to delete for a few
The "trash" icon appears above the key to be deleted.
» Press the trash icon
The key is deleted.
Creating a key
If fewer than nine default temperature keys are available, use the "+" key to add a new key.
»
Press the "+"
button.
The numeric keypad pop-up appears.
» Enter a setpoint temperature using the keypad
» Confirm by pressing the "✓" key
The pre-registered temperature button is created
4.7.2
TIME
The first time you press the keypad opposite the time-setting zone, a pop-up appears, displaying the time-setting zone and ten pre-registered keys,
each associated with a specific time. By selecting one of these keys, the corresponding value is automatically added to or subtracted from the time
setpoint.
The keypad below the ten preset values can be pressed to access a numeric keypad for manual entry of numbers. The numbers underlined by a line
indicate the value entry zone, with the minutes underlined by default. Pressing the keypad changes this selection. You can also click on the 'Hours' or
'Seconds' zones to enter a time value manually. Don't forget to validate the value entered to apply it.
CHEF'SCOMBI
seconds.
Page 18 / 161
EN
3V-490099EU – 04/25
