4 - GENERAL
4.1
CONTROL PANEL
Your oven's tempered glass control panel features a 10" screen and a knob with encoder surrounded by an illuminated ring.
4.1.1
BUTTON
Dual function button:
By pressing:
✓
Switching on and off the oven and screen
✓
Confirmation/validation of parameters/values
By rotation:
✓
Changing parameters / values
✓
Scroll vertically (list of Recipes, etc.)
4.1.2
LIGHT RING
The light ring indicates the operating status of the oven using 4 colours and 4 light effects.
Oven status
Type of cycle
At rest
Out of cycle (not on standby, not stopped)
In cycle
Start / load / unload
Preheating / Cooling
In progress
Recipes messages
Error messages
Standby
Standby
On cycle
Off
-
4.1.3
TOUCH SCREEN:
The use of the screen is inspired by "smartphone" type use. Simply touch the screen with your finger using the gestures below to access or validate
the various menus, settings and information.
Press
Selection / validation
CHEF'SCOMBI
The control panel is operated by pressing the screen-printed buttons with your fingers. We advise
you to use your fingers only and never any other object such as knives, forks, spoons, etc....
Swiper
Moving screens
4.
GENERAL
Ring colour
Ring light effect
Blue
Stable (no flash effect)
Green
Flash off / on
Red
Low with different intensity flash
Orange
Low with different intensity flash
Orange
Flash off / on
Green
Flash off / on
Orange
Flash off / on
Red
Flash off / on
Blue
Low with different intensity flash
Green
Low with different intensity flash
Orange
Low with different intensity flash
Red
Low with different intensity flash
-
No effect
Scroller
Scrolling a list
Page 14 / 161
EN
Drag and drop
Moving a widget
