4.13 Installation conforme à la norme UL
REMARQUE
En raison des exigences UL, le chapitre suivant est toujours en anglais, indépendam-
ment de la langue de la présente documentation.
REMARQUE
L'homologation UL et cUL pour les appareils suivants est en préparation.
•
•
4.13.1 (Field Wiring) Power Terminals
•
•
MCX91A-...-5_3-.. 0010 – 0055 0070 – 0160
MCX91A-...-2_3-.. 0017 – 0055 0070 – 0140
MCX91A-...-2_1-.. 0017 – 0042 0055 – 0110
Unit Size 0S
Screw connection
Line connection X1
Motor and braking X2
resistor connection
PE connections
Other M4 screw
connections
4.13.2

Short Circuit Current Rating

Suitable for use on a circuit capable of delivering not more than 65,000 rms symmetri-
cal amperes when protected by fuses, inverse time circuit breakers or Type E Combi-
nation Motor Controllers as described in the tables below:
•
•
Appareils de tailles 7 et 8
Appareils 1 x 230 V
Use 75 °C copper wire only.
Tightening torque and wire size for field wiring terminals:
0240 0320 – 0460 0620 – 0910 1130 – 1770
0213 0290 – 0420 0570 – 0840
–
0L 3
4.4 – 5.3
4.4 – 5.3
10.6 – 13.3
®
MOVITRAC MCX91B 0010 – 5880 (400 V units only)
– The max. voltage is limited to 500 V.
®
MOVITRAC MCX91B 0017 – 0140 (230 V units only)
– The max. voltage is limited to 240 V.
Installation conforme à la norme UL
– –
4 5
Tightening torques in in.lbs
15.0 – 15.9 75.2 – 84.1 88.5 – 132.8 123.9 – 177.0 123.9 – 177.0
15.0 – 15.9 75.2 – 84.1 88.5 – 132.8 123.9 – 177.0 123.9 – 177.0
26.6 – 35.4 53.1 – 88.5 88.5 – 132.8 123.9 – 177.0 123.9 – 177.0
12.4 – 14.2
Notice d'exploitation – MOVITRAC
Installation
2200 – 3000 3800 – 5880
1080 –
– –
6 7
®
