Installation conforme à la norme UL
4.13.3

Branch Circuit Protection

Model (Frame Size)
MCX91A-0017-2.3-4-...(0S)
MCX91A-0025-2.3-4-...(0S)
MCX91A-0034-2.3-4-...(0S)
MCX91A-0042-2.3-4-...(0S)
MCX91A-0055-2.3-4-...(0S)
MCX91A-0070-2.3-4-...(0L)
MCX91A-0093-2.3-4-...(0L)
MCX91A-0110-2.3-4-...(0L)
Model
MCX91A-0017-2.3-4-...(0S)
MCX91A-0025-2.3-4-...(0S)
MCX91A-0034-2.3-4-...(0S)
MCX91A-0042-2.3-4-...(0S)
MCX91A-0055-2.3-4-...(0S)
MCX91A-0070-2.3-4-...(0L)
MCX91A-0093-2.3-4-...(0L)
MCX91A-0140-2.3-4-...(0L)
MCX9.A-0213-2.3-4-... (3)
MCX91A-0290-2.3-4-... (4)
MCX91A-0420-2.3-4-... (4)
MCX91A-0570-2.3-4-... (5)
MCX91A-0840-2.3-4-... (5)
MCX91A-1080-2.3-4-... (6)
Model
MCX91A-0010-5.3-4-...(0S)
MCX91A-0016-5.3-4-...(0S)
MCX91A-0020-5.3-4-...(0S)
MCX91A-0025-5.3-4-...(0S)
104
Notice d'exploitation – MOVITRAC
Integral solid state short circuit protection does not provide branch circuit protection.
Branch circuit protection must be provided in accordance with the National Electrical
Code and any additional local codes (US) or Canadian Electrical Code, Part 1 (CA).
For maximum branch circuit protection see table below:
Single Phase 200 – 240 V Voltage Range
Non Semiconductor
Fuses (currents are
maximum values)
20 A / 250 V
25 A / 250 V
30 A / 250 V
40 A / 250 V
40 A / 250 V
60 A / 250 V
60 A / 250 V
60 A / 250 V
Three Phase 200 – 240 V Voltage Range
SCCR: 65 kA / 240 V
Non Semiconductor
Fuses (currents are
maximum values)
6 A / 250 V
6 A / 250 V
10 A / 250 V
15 A / 250 V
20 A / 250 V
25 A / 250 V
30 A / 250 V
30 A / 250 V
60 A / 600 V
Class: CA, CB, CD, CF, G,
J, K-1, K-5, RK1, RK5, T
60 A / 600 V
Class: CA, CB, CD, CF, G,
J, K-1, K-5, RK1, RK5, T
125 A / 600 V
Class: J, K-1, RK1, T
125 A / 600 V
Class: J, K-1, RK1, T
225 A / 600 V
Class: J, T
225 A / 600 V
Class: J, T
Voltage rating of BCP is permitted to be higher.
Three Phase 380 – 500 V Voltage Range
SCCR: 65 kA / 500 V
Non Semiconductor
Fuses (currents are
maximum values)
3 A / 600 V
3 A / 600 V
6 A / 600 V
6 A / 600 V
®
advanced
SCCR: 65 kA
Inverse-Time Circuit Brea-
ker (currents are maxi-
mum values)
20 A / 240 V
25 A / 240 V
30 A / 240 V
30 A / 240 V
30 A / 240 V
30 A / 240 V
30 A / 240 V
30 A / 240 V
Inverse-Time Circuit Brea-
ker (currents are maxi-
mum values)
15 A / 240 V min.
15 A / 240 V min.
15 A / 240 V min.
15 A / 240 V min.
20 A / 240 V min.
25 A / 240 V min.
30 A / 240 V min.
30 A / 240 V min.
60 A / 500 V min.
60 A / 500 V min.
125 A / 500 V min.
125 A / 500 V min.
225 A / 500 V min.
225 A / 500 V min.
Inverse-Time Circuit Brea-
ker (currents are maxi-
mum values)
15 A / 500 V min.
15 A / 500 V min.
15 A / 500 V min.
15 A / 500 V min.
Type E Combination Motor Control-
ler, mfd by Siemens, Type Sirius (ra-
ted 480V/277V)
3RV2011-1GA10, 6.3 A
3RV2011-1HA10, 8.0 A
3RV2011-1JA10, 10 A
3RV2011-4AA10, 16 A
3RV2011-4AA10, 16 A
3RV2011-4BA10, 20 A
3RV2011-4DA10, 25 A
3RV2011-4EA10, 32 A
Type E Combination Motor Control-
ler, mfd by Siemens, Type Sirius (ra-
ted 480V/277V)
3RV2011-1AA10, 1.6 A
3RV2011-1CA10, 2.5 A
3RV2011-1EA10, 4.0 A
3RV2011-1EA10, 4.0 A
3RV2011-1GA10, 6.3 A
3RV2011-1HA10, 8.0 A
3RV2011-1JA10, 10 A
3RV2011-4AA10, 16 A
3RV2021-4DA10, 25 A
3RV2031-4EA10, 32 A
3RV2031-4VA10, 45 A
3RV2041-4JA10, 63 A
3RV2041-4YA10, 93 A
3RV2041-4YA10, 93 A
Type E Combination Motor Control-
ler, mfd by Siemens, Type Sirius (ra-
ted 480V/277V)
3RV2011-0JA10, 1.0 A
3RV2011-1AA10, 1.6 A
3RV2011-1CA10, 2.5 A
3RV2011-1CA10, 2.5 A
