Redondance de réseaux
10.4 Media Redundancy Protocol
Exemple
Dans cet exemple, on active pour un abonné d'anneau le domaine de redondance
mrpdomain-1.
localhost# config
Entering configuration mode terminal
localhost(config)# switch mrp ring-id 1 domain-name mrpdomain-1
localhost(config-ring-id-1)# commit
Commit complete.
localhost(config-ring-id-1)# end
localhost# show running-config switch mrp ring-id 1 domain-name
switch
mrp
ring-id
exit
exit
exit
10.4.2.5
Modification du rôle MRP
Pour modifier le rôle MRP d'un appareil, procédez comme suit :
Opé‐
ration
1
2
3
4
5
Exemple
Dans cet exemple, on active le rôle MRP client pour un abonné d'anneau.
localhost# config
Entering configuration mode terminal
458
domain-name mrpdomain-1
Instruction
Passez en mode de configuration.
Modifiez le rôle MRP.
Options disponibles :
disabled - Aucun rôle MRP n'est affecté à
l'appareil. L'appareil n'est pas un abonné
de l'anneau MRP.
mrp-auto-manager - L'abonné de l'an‐
neau négocie automatiquement son rôle
MRP. En mode d'exploitation d'un anneau
MRP, l'abonné devient soit MRM, soit MRC.
mrp-manager - Le rôle invariable de
l'abonné de l'anneau est MRM.
mrp-client - Le rôle invariable de l'abon‐
né de l'anneau est MRC.
Validez la modification.
Quittez le mode de configuration.
Contrôlez la configuration.
Commande
config
switch mrp ring-id { 1 } mode
[ disabled | mrp-auto-manager |
mrp-manager | mrp-client ]
commit
end
show running-config switch mrp
ring-id { 1 } mode
Command Line Interface (CLI) SINEC OS V2.4
Manuel de configuration, 10/2023, C79000-G8977-C498-07
