Découverte et gestion de réseau
11.1 LLDP
Exemple
Dans cet exemple, on configure un intervalle d'émission de 50 secondes.
localhost# config
Entering configuration mode terminal
localhost(config)# lldp tx-interval 50
localhost(config-lldp)# commit
Commit complete.
localhost(config-lldp)# end
localhost# show running-config lldp tx-interval
lldp
tx-interval 50
exit
11.1.2.4
Définition de la temporisation de LLDPDU lors de l'initialisation von LLDP sur un
port de pont
Si l'envoi et/ou la réception de LLDPDUs ont été réactivés pour un port de pont à l'état
LLDP disabled, l'agent LLDP supprime la transmission de LLDPDUs pendant la période
configurée. LLDP reste encore inactif sur le port de pont correspondant pendant cette période.
Pour configurer la temporisation jusqu'à la réinitialisation de LLDP sur tous les ports de pont,
procédez comme suit :
Opé‐
ration
1
2
3
4
5
Exemple
Dans cet exemple, on configure une temporisation de 2 secondes.
localhost# config
Entering configuration mode terminal
localhost(config)# lldp reinit-delay 2
localhost(config-lldp)# commit
Commit complete.
localhost(config-lldp)# end
localhost# show running-config lldp reinit-delay
lldp
reinit-delay 2
exit
476
Instruction
Passez en mode de configuration.
Configurez le temps en secondes pendant le‐
quel l'agent LLDP attend avant d'envoyer à
nouveau des LLDPDU, même si LLDP est activé.
Par défaut : 1
Validez la modification.
Quittez le mode de configuration.
Contrôlez la configuration.
Commande
config
lldp reinit-delay { 1 - 10 }
commit
end
show running-config lldp reinit-
delay
Command Line Interface (CLI) SINEC OS V2.4
Manuel de configuration, 10/2023, C79000-G8977-C498-07
