Redondance de réseaux
10.1 Spanning Tree Protocol (STP)
Exemple
Dans l'exemple suivant, l'interopérabilité IEEE 802.1w est activée.
localhost# config
Entering configuration mode terminal
localhost(config)# switch spanning-tree erstp ieeedot1w-interoperability
localhost(config-switch-spanning-tree)# commit
Commit complete.
localhost(config-switch-spanning-tree)# end
localhost# show switch spanning-tree erstp ieeedot1w-interoperability
switch
spanning-tree
erstp ieeedot1w-interoperability
exit
exit
10.1.5
Configuration de MSTP
Pour configurer MSTP, procédez comme suit :
1. Sélectionnez le nombre maximal de sauts par lesquels les BPDU peuvent être retransmis dans
la région Multiple Spanning Tree (MST).
Pour plus d'informations, voir "Configuration du nombre maximal de sauts (Page 394)".
2. Ajoutez le nom de la région.
Pour plus d'informations, voir "Ajout du nom d'une région. (Page 395)".
3. Sélectionnez la version de la région.
Tous les ponts d'une région MST possèdent la même version.
Pour plus d'informations, voir "Configurez la version de la région (Page 396)".
4. Configurez une ou plusieurs instances Multiple Spanning Tree (MSTI).
Pour plus d'informations, voir "Configuration d'instances Multiple Spanning Tree (MSTI)
(Page 397)".
10.1.5.1
Configuration du nombre maximal de sauts
Pour configurer le nombre maximal de sauts, procédez comme suit :
Opéra‐
1
2
3
4
5
394
Instruction
tion
Passez en mode de configuration.
Sélectionnez le nombre maximal de sauts.
Par défaut : 20
Validez la modification.
Quittez le mode de configuration.
Contrôlez la configuration.
Commande
config
switch spanning-tree mstp max-
hops { 6 - 40 }
commit
end
show switch spanning-tree mstp
max-hops
Command Line Interface (CLI) SINEC OS V2.4
Manuel de configuration, 10/2023, C79000-G8977-C498-07
