Redondance de réseaux
10.4 Media Redundancy Protocol
localhost# config
Entering configuration mode terminal
localhost(config)# switch mrp ring-id 1
localhost(config-ring-id-1)# domain-name default-mrpdomain
localhost(config-ring-id-1)# mode mrp-auto-manager
localhost(config-ring-id-1)# ring-port1 ethernet0/3
localhost(config-ring-id-1)# ring-port2 ethernet0/4
localhost(config-ring-id-1)# commit
Commit complete.
localhost(config-ring-id-1)# end
localhost# show running-config switch mrp ring-id
% The following list contains 1 entry.
switch
mrp
ring-id 1
exit
exit
exit
10.4.2.3
Activer MRP globalement
MRP est désactivé par défaut.
Pour activer MRP globalement, procédez comme suit :
Opé‐
ration
1
2
3
4
5
Exemple
Dans cet exemple, on active MRP.
localhost# show switch device-config
General vlan device configuration
GVRP status
GMRP status
.
.
.
localhost# config
Entering configuration mode terminal
456
mode
mrp-auto-manager
ring-port1
ethernet0/3
ring-port2
ethernet0/4
domain-name
default-mrpdomain
Instruction
Passez en mode de configuration.
Activez MRP.
Validez la modification.
Quittez le mode de configuration.
Contrôlez la configuration.
Commande
config
switch mrp enabled
commit
end
show running-config switch mrp
enabled
disabled
disabled
Command Line Interface (CLI) SINEC OS V2.4
Manuel de configuration, 10/2023, C79000-G8977-C498-07
